29400 Spherical Roller Thrust Bearings

29400 Spherical Roller Thrust Bearings

Drawing

Datasheet

Bearing No.	Dimensions			Mass	Bearing No.	Dimensions			Mass
Bearing No.	d	D	H		Bearing No.	d	D	H
–	mm	mm	mm	kg	–	mm	mm	mm	kg
29412	60	130	42	2.6	29464	320	580	155	175
29413	65	140	45	3.2	29468	340	620	170	220
29414	70	150	48	3.9	29472	360	640	170	230
29415	75	160	51	4.7	29476	380	670	175	260
29416	80	170	54	5.6	29480	400	710	185	310
29417	85	180	58	6.75	29484	420	730	185	325
29418	90	190	60	7.75	29488	440	780	206	410
29420	100	210	67	10.5	29492	460	800	206	425
29422	110	230	73	13.5	29496	480	850	224	550
29424	120	250	78	17.5	294/500	500	870	224	560
29426	130	270	85	22	294/530	530	920	236	650
29428	140	280	85	23	294/560	560	980	250	810
29430	150	300	90	28	294/600	600	1030	258	845
29432	160	320	95	32	294/630	630	1090	280	1040
29434	170	340	103	44.5	294/670	670	1150	290	1210
29436	180	360	109	52.5	294/710	710	1220	308	1500
29438	190	380	115	60.5	294/750	750	1280	315	1650
29440	200	400	122	72	294/800	800	1360	335	2030
29444	220	420	122	75	294/850	850	1440	354	2390
29448	240	440	122	80	294/900	900	1520	372	2650
29452	260	480	132	105	294/950	950	1600	390	3070
29456	280	520	145	135	294/1000	1000	1670	402	3390
29460	300	540	145	140	294/1060	1060	1770	426	4280
